IRF540NPBF
IRF540N
33A 100V TO-220
Quantity
Essential details
Model Number:
IRF540NPBF
Type:
MOSFET
Place of Origin:
Original
Brand Name:
Original Brand
D/C:
21+
Package Type:
Throught Hole
Application:
-
Supplier Type:
Original manufacturer, ODM, Agency, Retailer, Other
Brand:
MOSFET N-CH 100V 33A TO220AB
Current - Collector (Ic) (Max):
-
Voltage - Collector Emitter Breakdown (Max):
-
Vce Saturation (Max) @ Ib, Ic:
-
Current - Collector Cutoff (Max):
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
-
Power - Max:
-
Frequency - Transition:
-
Operating Temperature:
-55°C ~ 175°C(TJ)
Mounting Type:
Through Hole
Package / Case:
TO-220-3
Resistor - Base (R1):
-
Resistor - Emitter Base (R2):
-
FET Type:
N-Channel
FET Feature:
-
Drain to Source Voltage (Vdss):
100 V
Current - Continuous Drain (Id) @ 25°C:
33A(Tc)
Rds On (Max) @ Id, Vgs:
44ha @ 16A,10V
Vgs(th) (Max) @ Id:
4V @ 250uA
Gate Charge (Qg) (Max) @ Vgs:
71 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds:
1960 pF @ 25 V
Frequency:
-
Current Rating (Amps):
-
Noise Figure:
-
Power - Output:
-
Voltage - Rated:
-
Drive Voltage (Max Rds On, Min Rds On):
10V
Vgs (Max):
±20V
IGBT Type:
-
Configuration:
-
Vce(on) (Max) @ Vge, Ic:
-
Input Capacitance (Cies) @ Vce:
510 pF @ 25 V
Input:
-
NTC Thermistor:
-
