category

Discrete semiconductor products

Diode rectifier single

packing

Roll tape (TR)

Shear band (CT)

Diode type

standard

Current average rectification (Io)

2A

Voltage at different If - forward (Vf)

1.15 V @ 2 A

speed

Standard recovery>500ns,>200mA (Io)

Reverse recovery time (trr)

1.5 µs

Current - reverse leakage at different Vr

1 µA @ 1000 V

Capacitance at different Vr and F

30pF @ 4V，1MHz

Installation type

Surface mount

Encapsulation/Housing

DO-214AA，SMB

Supplier device packaging

DO-214AA（SMB）

Operating temperature junction

-55°C ~ 150°C
