Integrated circuit,Discrete semiconductor products Diode-rectifier,STTH8L06FP
STTH8L06FP
Integrated circuit,Discrete semiconductor products Diode-rectifier,STTH8L06FP
Quantity
STTH8L06FP,Discrete semiconductor products Diode-rectifier manufacturer STMicroelectronics package pipe fitting Diode type standard Voltage-DC Reverse (Vr) (max) 600 V Current-average rectification (Io) 8A Voltage-Forward (Vf) at Different If Times 1.3 V 8 A speed Fast recovery =< 500ns, > 200mA(Io) Reverse recovery time (trr) 105 ns Current at different Vr times-reverse leakage 8 µA 600 V Capacitance at different Vr and F - Installation type through-hole Package/housing TO-220-2 full package, isolation tab Supplier device package TO-220FPAC Working temperature 175°C (max)
