touch switch
6*6 Surface mount type
switch touch switch,6*6 Surface mount type
Quantity
category switch touch switch series TS04 package bag circuit SPST-NO Switch function Off-instantaneous Rated contact current at different voltages 0.05A 12VDC Actuator type standard Installation type Surface mount type Height of actuator from PCB, vertical 5.50mm Actuator length, right angle - Actuator direction Top touch Termination style Gull wing appearance 6.00mm x 6.00mm illuminate non-luminance Operating force 100gf Intrusion protection - trait - Working temperature -30°C ~ 80°C Actuator material Polyamide (PA66), nylon 6/6 Switch stroke 0.25mm mechanical life 100,000 cycles
